0.75kW Silent compressor 8bar soundproofed 230V 10l boiler – 02657

Description

0.75kW Silent Compressor 8bar soundproofed 230V with 10Liter Boiler

CP15OSJ-02657

This new range of silent compressors at Pro-Lift-Montagetechnik have a low noise level and high air efficiency. Forced air cooling provides a central cooling air flow that increases compressor life and efficiency.

Thanks to a direct drive and oil-free operation, the quiet compressors produce hundreds of hours of clean air maintenance-free. The silent compressors are also equipped with a variable start-up mode up to 1.2bar, which prevents a high start-up peak.

Oil-free compressor unit

the innovative design allows highest performance with maximum comfort at low noise level

with 2 pressure gauges for the boiler pressure and for the outlet pressure

integrated pressure regulator

compact and portable

with all safety fittings

Condensate drainage device

Supplied with power cable and plug

Technical data :

max power                 : 0.75kW

Connection                : 230V

frequency                   : 50Hz

Speed of the motor   : 1420rpm

Oil-free compressor unit

speed                         : 1420rpm

max. tank pressure    : 11bar

set cut-off pressure   : 8bar

Starting pressure       : 6bar

Suction volume         : 195l/min

air flow rate               : 150l/min

tank capacity             : 10litres

duty cycle                  : 40%

Noise level                : 76 dB (@1m)

Air connection quick connector with Euroline standard quick connector

Dimensions LxWxH   : 390mm x 350mm x 630mm

Weight                      : 27kg

Shipping weight       : 31kg

Self pick up is possible after telephone arrangement.
